10 Best Lcr Meters 2025 in the United States

The DE-5000 Handheld LCR Meter is a versatile and high-accuracy device designed to measure inductance, capacitance, and resistance, along with secondary parameters like dissipation factor, quality factor, and phase angle. Its dual display can show up to 19999/9999 counts, ensuring precise readings. One of its standout features is the fully auto-ranging capability for AC impedance and DC resistance, making it user-friendly as there is no need to manually select the function key in 'AUTO-LCR' mode. Additionally, it can measure components in both serial and parallel modes automatically, which is a significant convenience for users dealing with various devices under test (DUT).

The LCR meter offers a wide range of selectable test frequencies (100Hz, 120Hz, 1kHz, 10kHz, 100kHz), allowing for flexibility in testing different components. Another useful feature is the 'Sorting' mode, which helps users quickly sort a batch of components. The meter comes with a set of standard accessories such as an English PDF manual, alligator test lead case, SMD tweezers case, and guard line, though the IR to USB case is optional and not included.

Weighing 450 grams and powered by a 9V battery, the DE-5000 is relatively portable and suitable for fieldwork or using on-the-go. However, the device may be slightly bulky for some users' preferences, and the lack of built-in USB connectivity might be seen as a drawback for those who need data logging and computer interfacing capabilities.

The MATRIX Benchtop LCR Meter MCR5200 is a robust and precise device designed for measuring inductance, capacitance, and resistance. Its measurement range is quite extensive, covering 0.01 μH to 99999 H for inductance, 0.01 pF to 9.9999 F for capacitance, and 0.1mΩ to 99.999 MΩ for resistance, making it suitable for a wide array of applications. The meter's 0.1% basic measurement accuracy ensures reliable results, which is essential for professionals needing high precision.

The inclusion of 41 frequency points ranging from 40Hz to 200kHz provides flexibility for various testing scenarios, enhancing its usability in diverse settings like electronic component testing and laboratory research. The 4.3-inch TFT LCD display, featuring a 5-digit readout, enables clear and straightforward data reading. The device also supports multiple connectivity options such as USB HOST, RS232C, and GPIB command, which facilitates easy data transfer and integration into existing systems.

Additionally, the capability to save test data and copy screens to a U-disk in FAT16 or FAT32 format is a convenient feature for documentation and further analysis. However, the MCR5200 is not particularly portable due to its weight of 7.7 pounds and dimensions of 9.45 x 13.08 x 3.94 inches. This makes it more suitable for a benchtop setup rather than field use. The device operates on corded electric power, which can limit its flexibility in environments without easy access to power outlets. Despite these minor drawbacks, the MATRIX MCR5200 is a highly capable and user-friendly LCR meter that meets the needs of professionals requiring accurate and versatile testing equipment.

The B&K Precision 891 Benchtop LCR Meter is designed for professionals and hobbyists who need precise measurements of inductance, capacitance, resistance, and more. With a measurement range up to 300 kHz and an impressive accuracy of 0.05%, it excels in providing reliable and accurate data, which is crucial for tasks requiring high precision in electronic testing. The selectable test levels of 0.5 Vrms and 1 Vrms allow for flexibility, making it suitable for various testing environments and components.

The test frequency range of 20 Hz to 300 kHz suits a wide array of applications, notably in electronic design and repair, where the ability to test different frequencies can significantly enhance analysis. The measurement parameters available, including C, L, R, G, and others, provide a comprehensive toolset for detailed electronic assessments.

As a benchtop model, its portability is limited compared to handheld alternatives, which could be a drawback for users needing a more mobile solution. The size and weight of 11.28 pounds also make it less convenient for on-the-go testing. It is advisable to check the clarity and size of the display to ensure it meets your visibility needs.
